Monitoring in practice
Case Studies
Field installations and monitoring results from mines, dams and reservoir slopes in China.
MineXichang Vanadium–Titanium Magnetite Mine — Mine Monitoring
RT-1010 Array Displacement Meters monitor deep movement on the mine's north and south open-pit slopes. Twelve boreholes, averaging 38 m deep, provide displacement profiles for slope assessment and reinforcement decisions.
Read case study
DamShuangjiangkou Dam — Dam Monitoring
Horizontal RT-1010 Array Displacement Meter strings monitor settlement in the dam core and upstream rockfill. More than 1,000 m of arrays were installed at three elevations, with reference connections and installation checks.
Read case study
SlopeUpstream Slope Monitoring at Bala Hydropower Station
High-precision GNSS and RT-1010 Array Displacement Meters monitor surface and subsurface movement on the upstream slope near Sejiang Village, supporting slope assessment and reservoir management.
Read case study
